•2A Output Current
• Up to 95% Efficiency
• 6.0V to 30V Input Range
• 210kHz Switching Frequency
• Adjustable Output Voltage
• Cycle-by-Cycle Current Limit Protection
• Thermal Shutdown Protection
• Frequency Foldback at Short Circuit
• Stability with Wide Range of Capacitors, Including Low ESR Ceramic Capacitors
• SOP-8 Package
APPLICATIONS
• TFT LCD Monitors
• Portable DVDs
• Car-Powered or Battery-Powered Equipments
• Set-Top Boxes
• Telecom Power Supplies
• DSL and Cable Modems and Routers
• Termination Supplies
一般的描述：
ACT4065A是电流型降压 直流/直流转换器,生成输出 目前在210 khz切换频率。ACT4065A是高效的最高效率在95%在操作。保护功能包括逐周期电流限制,热关闭,在短路频率返送。在SOP-8包和ACT4065A可用需要很少的外部设备进行操作。
注意:ACT4065A dropin替代ACT4065
